Design Specs:
- Available in 36”, 42”, 48”, 54”, 60”, 66” and 72” widths
- Generously proportioned 32” depth of liner provides an exceptional capture area and performance
- Design of the stainless steel commercial baffle filters adds a professional form and superior performance
Product Features:
- Proprietary internally-sealed 3-speed motors deliver 1200 CFM or 2300 CFM
- Heavy gauge commercial stainless steel (#304 grade with #4 brush finish)
- Four 12” by 14” baffle filters improve performance (six or eight filters on larger models)
- Dimmable 50 watt halogen lights
- Optional in-line blowers deliver 1266 CFM
Installation & Care:
- Remote blower models are pre-wired for use with most in-line or exterior blowers
- Liners with internal blowers are all pre-wired and pre-assembled
- Top 10” round discharge (two 10” on larger models)
- Durable, dishwasher safe commercial stainless steel baffle filters
- All stainless steel interior design is easy to keep clean and eliminates grease traps
Specifications | |
---|---|
HALOGEN LIGHTS | 4 |
3-SPEED INTERNAL BLOWER | Yes |
CFM | 2300 |
DIMMABLE LIGHT CONTROL | Yes |
S/S BAFFLE FLITERS | Yes |
DUCT COLLAR | 2 X 10" |
